| Head |
On-demand Piezo head (Array of 3 heads stagger) |
| Print resolution |
300, 450, 600, 900, 1,200dpi |
| Ink |
Type |
UV curable ink : LUS-120 (C, M, Y, K, W, Cl) |
| UV curable ink : LUS-150 (C, M, Y, K, Lc, Lm, W) |
UV curable ink : LUS-211 (C, M, Y, K, W, Cl)
*Only available in some regions. |
| UV curable ink : LUS-350 (C, M, Y, K, W, Cl) |
| UV curable ink : LH-100 (C, M, Y, K, Lc, Lm, W, Cl) |
| Primer: PR-200 *1 |
| Ink Supply system |
1liter bottle, 250ml bottle (LH-100, LUS-120, PR-200 only) *2 |
| Ink circulation system *3 |
White ink circulation using Mimaki Circulation Technology (MCT) |
| Maximum diagram dimensions (W×D) |
2,500×1,300 mm (98.4×51.2") |
| Media |
Dimensions (W×D) |
2,500×1,300 mm (98.4×51.2") |
| Height |
Max. 50 mm (2.0") |
| Weight |
Less than 50 kg/m2 (10.2 lb./ft2), non concentrated load |
| Media absorption |
|
Blower adsorption type + foot switch |
| |
Number of absorption
area partitions |
2 partitions (X-axis direction) |
| Curing device |
LED-UV system |
| Interface |
USB2.0, Ethernet |
| Safety standard |
VCCI class A, CE mark, CB report, U.S. safety standard UL (UL62368-1), RoHS Directive, FCC Class A, Machinery directive, EAC, RCM |
| Input power supply |
Single phase, AC 200-240 V, 50/60 Hz, less than 12 A |
| Power consumption |
Less than 2.88 kVA |
| Installation environment |
Temperature |
15 – 30 °C (59 – 86 °F) |
| Relative humidity |
35 – 65 %Rh |
| Accuracy maintained temperature |
20 – 25 °C (68 – 77 °F) |
| Temperature gradient |
Less than ± 10 °C/h (± 18 °F/h) |
| Dust |
Similar to standard office environments |
| Assembled Dimensions (W×D×H) |
4,400×2,450×1,250 mm (173.2×96.4×49.2") |
| Weight |
650 kg (1,433 lbs.) |
